What is a robotic tool changer?

A robotic tool changer is a device that automatically swaps end effectors or tools on a robot arm during operation without manual intervention. The TripleA Robotics WINGMAN enables fast and secure automatic tool changes, allowing a single robot to perform multiple tasks like palletizing, pick-and-place, assembly, and welding by switching between different tools.

Can the WINGMAN tool changer work with Universal Robots?

Yes, the WINGMAN Automatic Tool Changer installs in one minute on Universal Robots using URcap software. It mounts on a standard ISO flange and requires no complex setup.

Is the WINGMAN compatible with FAIRINO cobots?

The WINGMAN Automatic Tool Changer is compatible with FAIRINO FR3, FR3(WMS), FR3(WML), FR5, FR10, FR16, FR20, FR30, and FR35 models. It mounts on the standard ISO flange interface found on these robots.

How much weight can the WINGMAN tool changer hold?

The WINGMAN Automatic Tool Changer holds payloads up to 33 kg with positioning repeatability of plus or minus 0.03 mm, making it suitable for high precision applications. The changer itself weighs only 260 g and adds just 30 mm to the robot's height.

Can I route cables through the WINGMAN tool changer?

Yes, the WINGMAN features modular pass-through modules that allow you to route cables perfectly for flexible integration of multiple end effectors. This supports clean cable management during tool switching.

Not sure it fits your cell? Book 20 minutes with an engineer who has specified this part before.

Book a call

Ordered the wrong size or interface? Here is exactly how sending it back works.

In StockHandles 200 kg

TripleA Robotics WINGMAN Automatic Tool Changer, 33 kg

Name: TripleA Robotics WINGMAN Automatic Tool Changer, 33 kg
Brand: TripleA Robotics
SKU: 1014
Price: 3295 USD
Availability: InStock

TripleA Robotics

$3,295.00

Automatic tool changer for collaborative robots with 33 kg payload, ±0.03 mm repeatability, and one-minute setup via URcap software. Compact 260 g assembly adds just 30 mm height, features ISO flange interface, and supports FAIRINO FR3 through FR35 cobot models.

Overview:

TripleA Robotics WINGMAN Automatic Tool Changer is a robot tool changer designed for collaborative robots in automation, supporting rapid and reliable automatic tool change for high precision tasks.

Headline Specifications:

Payload: 33 kg
Positioning Repeatability: ±0.03 mm
Weight: 260 g
Height Addition: 30 mm
Interface: Standard ISO flange

Compatibility:

The WINGMAN Automatic Tool Changer integrates with Universal Robots platforms using URcap software and is compatible with FAIRINO cobot models FR3, FR3(WMS), FR3(WML), FR5, FR10, FR16, FR20, FR30, and FR35. This allows users to standardize end effectors and tooling across diverse installations.

Features:

Enables fast and secure automatic tool change during operation.
Provides modular pass-throughs for flexible cable routing.
Installation time is reduced to one minute on Universal Robots using URcap.
Supports multi-tool deployments and high precision applications.

Applications:

Palletising
Pick-and-place
Machine tending
Assembly and welding

Buyer Considerations:

WINGMAN Automatic Tool Changer is ideal when frequent tool switching, minimal downtime, and repeatable accuracy are critical in industrial cobot deployments.
Mounts to robots with a standard ISO flange; compatible with Universal Robots and FAIRINO families.
Suitable for installations requiring quick changeover and flexible integration of multiple end effectors.

Related Products and Categories:

End Effectors & Tooling category for other robot tool changers.

Weight0.26 kg

Weight260 g

Repeatability±0.03 mm

Combined height: 30 mm
Combined weight: 260 g
Rated payload: 33 kg
Standard ISO flange: Yes
Payload: 33 kg
Height: 30 mm
Mounting Interface: ISO flange
Compatible Models: FAIRINO FR3
FAIRINO FR3(WMS)
FAIRINO FR3(WML)
FAIRINO FR5
FAIRINO FR10
FAIRINO FR16
FAIRINO FR20
FAIRINO FR30
FAIRINO FR35
Setup time: 1 minute
Compatible software: URcap for Universal Robots

Route cables perfectly through modular pass-through modules
Holds 33 kg payloads with ±0.03 mm repeatability
Adds just 30 mm height, weighs only 260 g
Mounts on standard ISO flange for universal compatibility
Installs in one minute on Universal Robots with URcap
Works with FAIRINO FR3, FR3(WMS), FR3(WML), FR5, FR10, FR16, FR20, FR30, FR35
Enables rapid tool switching for palletizing, pick-and-place, machine tending, assembly, welding

: A robotic tool changer is a device that automatically swaps end effectors or tools on a robot arm during operation without manual intervention. The TripleA Robotics WINGMAN enables fast and secure automatic tool changes, allowing a single robot to perform multiple tasks like palletizing, pick-and-place, assembly, and welding by switching between different tools.
: Yes, the WINGMAN Automatic Tool Changer installs in one minute on Universal Robots using URcap software. It mounts on a standard ISO flange and requires no complex setup.
: The WINGMAN Automatic Tool Changer is compatible with FAIRINO FR3, FR3(WMS), FR3(WML), FR5, FR10, FR16, FR20, FR30, and FR35 models. It mounts on the standard ISO flange interface found on these robots.
: The WINGMAN Automatic Tool Changer holds payloads up to 33 kg with positioning repeatability of plus or minus 0.03 mm, making it suitable for high precision applications. The changer itself weighs only 260 g and adds just 30 mm to the robot's height.
: Yes, the WINGMAN features modular pass-through modules that allow you to route cables perfectly for flexible integration of multiple end effectors. This supports clean cable management during tool switching.

Automatic tool changer versus manual swap or lower-payload changers:

The WINGMAN supports 33 kg payloads with ±0.03 mm repeatability, making it suitable for high-precision multi-tool workflows on Universal Robots and FAIRINO cobots. Choose this when tool switching frequency and accuracy matter more than keeping the robot arm lightweight.

For palletizing or pick-and-place lines that change grippers mid-shift, automatic exchange eliminates manual downtime and repositioning error.
On shared cobot cells running assembly, welding, or machine tending, the 260 g changer weight and 30 mm height leave payload for larger or heavier end effectors than single-tool setups.
Where ±0.03 mm repeatability is required (tight tolerances in assembly or precision placement), the locked coupling ensures tool re-docking in the same position every cycle.
On Universal Robots, one-minute URcap installation and ISO flange compatibility avoid custom adapters and integration delays.
