What is a parallel gripper?

A parallel gripper uses two jaws that move toward each other in synchronized motion to grip workpieces between them. The Effecto Group EIG2-40400 has parallel jaws with a 40 mm stroke per jaw and can handle workpieces up to 8 kg with 800 N maximum gripping force.

What is the main purpose of a gripper?

A gripper is an end effector that grasps and holds workpieces during automated tasks like assembly, material transfer, and pick-and-place operations. The EIG2-40400 provides programmable force control and 0.02 mm repeatability for precise handling of small parts in industrial automation.

Is gripper an actuator?

A gripper functions as an actuator because it converts control signals into mechanical motion to grip and release parts. The EIG2-40400 is an electric gripper with an embedded controller that responds to Modbus RTU and EtherCAT commands to adjust gripping force, position, and cycle speed.

Can the EIG2-40400 mount in different orientations?

Yes, the EIG2-40400's compact 2.4 kg design supports multiple mounting orientations including direct mounting to robotic arms, flat surfaces, vertical surfaces, and custom end-of-arm tooling interfaces for flexible integration.

What communication protocols does the EIG2-40400 support?

The EIG2-40400 supports Modbus RTU for legacy control systems and EtherCAT for real-time synchronous communication, with expandable compatibility for USB, Ethernet, CAN, and PROFINET for broader connectivity options.

What are the operating conditions for the EIG2-40400?

The EIG2-40400 operates in ambient temperatures up to 40 degrees Celsius with IP40 to IP54 protection ratings depending on configuration, providing factory floor durability with low noise operation.

Effecto Group EIG2 Electric Parallel Gripper, 40 mm, 800 N

Not sure it fits your cell? Book 20 minutes with an engineer who has specified this part before.

Book a call

Ordered the wrong size or interface? Here is exactly how sending it back works.

In Stock800N Grip

Effecto Group EIG2 Electric Parallel Gripper, 40 mm, 800 N

Name: Effecto Group EIG2 Electric Parallel Gripper, 40 mm, 800 N
Brand: Effecto Group
SKU: 3325
Price: 3795 USD
Availability: InStock

Effecto Group SpA

$3,795.00

Electric parallel gripper with 40 mm stroke per jaw, 800 N gripping force, and 0.02 mm repeatability. Programmable force and position control via embedded controller. Modbus RTU and digital I/O standard, expandable to Ethernet, CAN, PROFINET, EtherCAT. Compact design for flexible mounting. Rated IP40-IP54, operating to 40°C.

The Effecto Group EIG2-40400 electric parallel gripper is an adaptive, programmable gripper for industrial automation end effector applications including small-part handling, precise assembly, and material transfer tasks.

Key Specifications:

Stroke: 40 mm per jaw
Gripping Force: 800 N maximum
Repeatability: 0.02 mm
Weight: 2.4 kg

Applications and Suitability:

Effecto Group's EIG2-40400 is developed for automated assembly, machine tending, and pick-and-place operations where precise force control is required. Its compact rectangular design supports multiple mounting orientation options for flexible integration as an industrial automation end effector. Typical workpieces suitable for the EIG2-40400 include small parts up to 8 kg.

Mounting and Jaw Configuration:

Jaw configuration: Parallel motion with 40 mm stroke
Mounting options: Direct mounting to robotic arms, flat or vertical surfaces, and custom end-of-arm tooling interfaces

Programmability and Force Control:

The embedded controller in the EIG2-40400 allows for adjustment of gripping force, position, and cycle speed for adaptive handling of diverse part geometries.

Communication Protocols Explained:

Modbus RTU: Reliable integration with legacy control systems
EtherCAT: Synchronous high-speed communication for real-time control
Expansion: USB, Ethernet, CAN, PROFINET compatibility for broader connectivity

EIG2 Series Variant Comparison:

Sizing options: Four variants with strokes from 6 mm to 40 mm
Force range: Up to 280 N for smaller models, 800 N for EIG2-40400

Choose the EIG2-40400 for applications requiring maximum stroke and force. Other EIG2 sizes cover lighter payloads and reduced strokes for small-part gripper tasks.

Usage Conditions:

Ambient operating temperature up to 40°C
Protection ratings: IP40 to IP54 depending on configuration
Low noise operation for factory environments

FAQ:

What workpiece sizes fit? Workpieces up to 8 kg with widths within 40 mm jaw stroke.
What mounting options are available? Direct to end-of-arm tooling, vertical or horizontal surfaces, flexible integration with standard interface plates.
Which protocols are supported? Modbus RTU for legacy systems, EtherCAT for high-speed synchronization, expandable to USB, Ethernet, CAN, and PROFINET.

Product Schema, Review and URL Guidance:

Use Product schema markup to specify brand Effecto Group, model EIG2-40400, headline specs, availability, and pricing for rich snippet optimization. If collecting reviews, implement aggregateRating schema for buyer confidence. Recommended URL for search visibility: /electric-parallel-grippers/eig2-40400.

Alt Text Guidance for Visual Content:

Show gripper size comparison against a standard robotic wrist
Depict multiple mounting options (side, base, flange)
Clearly display parallel jaw configuration with open and closed positions

Weight22.4 kg

Weight2.4 kg

Stroke per jaw40 mm

Max Gripping force: 800 N
Recommended workpiece weight: 1.8 kg
Propulsion Method: Electric
Max. ambient temperature: 40 ℃
Repeatability: 0.02 mm
Model: EIG2-40400
Stroke: 40 mm
Gripping Force: 800 N
Payload: 8 kg
Mounting Interface: Rectangular, multiple orientations
Ambient Temperature: 40°C
IP Rating: IP40 to IP54

Grips small parts adaptively with programmable force control, 800 N maximum
Precise repeatability of 0.02 mm for consistent assembly tasks
40 mm stroke per jaw handles workpieces up to 8 kg
Compact 2.4 kg design fits multiple mounting orientations on robotic arms
Modbus RTU and EtherCAT communication for legacy and real-time control systems
IP40 to IP54 protection rated for factory floor conditions
Operates quietly up to 40°C ambient temperature in industrial automation

: A parallel gripper uses two jaws that move toward each other in synchronized motion to grip workpieces between them. The Effecto Group EIG2-40400 has parallel jaws with a 40 mm stroke per jaw and can handle workpieces up to 8 kg with 800 N maximum gripping force.
: A gripper is an end effector that grasps and holds workpieces during automated tasks like assembly, material transfer, and pick-and-place operations. The EIG2-40400 provides programmable force control and 0.02 mm repeatability for precise handling of small parts in industrial automation.
: A gripper functions as an actuator because it converts control signals into mechanical motion to grip and release parts. The EIG2-40400 is an electric gripper with an embedded controller that responds to Modbus RTU and EtherCAT commands to adjust gripping force, position, and cycle speed.
: Yes, the EIG2-40400's compact 2.4 kg design supports multiple mounting orientations including direct mounting to robotic arms, flat surfaces, vertical surfaces, and custom end-of-arm tooling interfaces for flexible integration.
: The EIG2-40400 supports Modbus RTU for legacy control systems and EtherCAT for real-time synchronous communication, with expandable compatibility for USB, Ethernet, CAN, and PROFINET for broader connectivity options.
: The EIG2-40400 operates in ambient temperatures up to 40 degrees Celsius with IP40 to IP54 protection ratings depending on configuration, providing factory floor durability with low noise operation.

Electric parallel gripper vs pneumatic and magnetic alternatives:

The EIG2 is an electric parallel gripper designed for precise, programmable control of gripping force and speed, making it stronger for delicate precision work than pneumatic or magnetic grippers when you need repeatable part placement and adaptive handling across varied geometries.

For assembly tasks on small parts under 8 kg where 0.02 mm repeatability matters, the electric force control prevents over-gripping damage that fixed-force pneumatic grippers risk.
In high-mix production lines handling different part sizes and materials, programmable force adjustment avoids tool changeover that fixed-jaw magnetic grippers require.
On crowded robotic cells or collaborative arms where mounting space is tight, the compact 2.4 kg design and multiple mounting orientations fit where bulkier pneumatic manifolds cannot.
For legacy factory automation running Modbus RTU or real-time systems needing EtherCAT sync, the dual protocol support integrates without rewiring older control architectures.
In clean-room or noise-sensitive environments, quiet electric operation suits factories where pneumatic hiss creates worker fatigue or monitoring interference.
