What is an electric gripper?

An electric gripper is a powered end effector that uses electrical energy to open and close fingers for gripping workpieces. The DH Robotics AG3 operates on 24 V DC and uses an electric screw nut and linkage mechanism to grip objects with forces ranging from 10 to 65 N per jaw.

What is the main purpose of a gripper?

A gripper picks up, holds, and positions workpieces in robotic automation tasks like assembly, machine tending, packaging, and material handling. The AG3 is designed to grip and precisely position irregular or cylindrical objects with repeatability of ±0.03 mm across its 106 mm stroke.

Can the DH Robotics AG3 handle irregular shaped parts?

Yes, the AG3 features an adaptive linkage design with three independent fingers that conform to irregular shapes and geometries. This adaptive design allows it to securely handle varied workpiece shapes while maintaining precise positioning.

What communication protocols does the AG3 Electric Gripper support?

The AG3 integrates via TCP/IP, USB 2.0, CAN 2.0A, and optional EtherCAT, making it compatible with most industrial robot control systems. It operates on 24 V DC at 0.5 A rated current with a peak draw of 1.0 A.

Is the AG3 suitable for food processing applications?

The AG3 is sealed with an IP40 protection rating and operates in controlled environments from 0 to 40°C, making it appropriate for food processing among other industries like automotive assembly and electronics manufacturing. Its quiet operation at under 60 dB also suits noise-sensitive production areas.

What is the maximum weight an AG3 can grip?

The DH Robotics AG3 can handle a maximum workpiece weight of 1.8 kg with gripping forces between 10 and 65 N per jaw. The exact grip strength depends on the workpiece geometry and how the adaptive fingers conform to it.

Not sure it fits your cell? Book 20 minutes with an engineer who has specified this part before.

Book a call

Ordered the wrong size or interface? Here is exactly how sending it back works.

In Stock60 N Grip

DH Robotics AG3 Electric Gripper, 3-finger, 10-65 N

Name: DH Robotics AG3 Electric Gripper, 3-finger, 10-65 N
Brand: DH Robotics
SKU: 1006
Price: 9995 USD
Availability: InStock

DH Robotics

$9,995.00

DH Robotics AG3 three-finger electric gripper with 10-65 N force per jaw, 106 mm stroke, and adaptive linkage design for handling workpieces up to 1.8 kg. Communicates via TCP/IP, USB, and CAN; 24 V DC powered; IP40 rated; CE certified.

The DH Robotics AG3 Electric Gripper is an adaptive gripper featuring three fingers, designed for robotic end effector applications in automotive assembly, electronics manufacturing, and food processing.

Gripper Specifications:

Gripping force: 10–65 N per jaw
Maximum workpiece weight: 1.8 kg
Parallel stroke: 106 mm, centric stroke: 122 mm
Positional repeatability: ±0.03 mm

The AG3 uses a screw nut and linkage mechanism, allowing all three fingers to conform to diverse geometries for adaptive handling. Its electric design supports parallel gripper and collaborative gripper tasks with robots operating in controlled industrial environments.

Connectivity and Integration:

Interfaces: TCP/IP, USB 2.0, CAN 2.0A, optional EtherCAT
Power: 24 V DC, 0.5 A rated, 1.0 A peak
Noise level: less than 60 dB
Operating range: 0–40°C, up to 85% relative humidity
Protection rating: IP40

Certifications and Quality:

Certified according to CE, FCC, RoHS standards
Manufactured by DH Robotics, a leader in robotic grippers

Best Gripper for:

Robotic pick-and-place, machine tending, packaging, material handling
Applications requiring adaptive gripping of irregular or cylindrical workpieces

How to Choose a Gripper:

Consider the required gripping force, finger design, stroke dimensions, and compatibility with your robot’s communication protocols when selecting the DH Robotics AG3 Electric Gripper. For tasks involving collaborative robots and sensitive workpieces, the AG3 is a reliable electric parallel gripper solution.

What is an Adaptive Gripper?

An adaptive gripper, such as the DH Robotics AG3, adjusts its three-finger geometry to securely handle varied shapes and sizes, improving efficiency in robotic automation.

If you are comparing alternatives, explore our selection of collaborative grippers and other robotic end effectors or consult our robot arms category for integration options.

Weight1.68 kg

Gripping force (per jaw)10~65 N

Recommended workpiece weight: 1.8 kg
Opening/Closing time: 0.7 s/0.7 s
Repeat accuracy (position): ± 0.03 mm
Noise emission: < 60 dB
Driving method: Screw nut + Linkage mechanism
Communication Interface: EtherCAT
USB2.0
CAN2.0A
TCP/IP
Rated voltage: 24 V DC ± 10%
Rated current: 0.5 A
Peak current: 1.0 A
IP class: IP 40
Recommended environment: 0~40°C
under 85% RH
Certification: CE
FCC
RoHS
Payload: 1.8 kg
Gripping Force: 10 to 65 N
Stroke: 106 mm parallel, 122 mm centric
Closing/Opening Time: 0.7 s
Repeatability: ±0.03 mm
Power Supply: 24 V DC
Current: 0.5 A rated, 1.0 A peak
Operating temperature: 0 to 40°C
Humidity: Up to 85% RH
Noise Level: Below 60 dB
IP Rating: IP40
Stroke Length (parallel): 106 mm
Stroke Length (centric): 122 mm

Adaptive linkage design conforms to irregular shapes, three independent fingers
Grips with precision, 10-65 N per jaw, 1.8 kg max workpiece
Precise positioning, ±0.03 mm repeatability across 106 mm parallel stroke
Runs quiet on 24 V DC, under 60 dB noise level
Sealed for production, IP40 rated across 0-40°C operating range
Integrates seamlessly, TCP/IP, USB 2.0, CAN 2.0A, optional EtherCAT
Built to standards, CE, FCC, RoHS certified
EtherCAT is available as an optional interface.

: An electric gripper is a powered end effector that uses electrical energy to open and close fingers for gripping workpieces. The DH Robotics AG3 operates on 24 V DC and uses an electric screw nut and linkage mechanism to grip objects with forces ranging from 10 to 65 N per jaw.
: A gripper picks up, holds, and positions workpieces in robotic automation tasks like assembly, machine tending, packaging, and material handling. The AG3 is designed to grip and precisely position irregular or cylindrical objects with repeatability of ±0.03 mm across its 106 mm stroke.
: Yes, the AG3 features an adaptive linkage design with three independent fingers that conform to irregular shapes and geometries. This adaptive design allows it to securely handle varied workpiece shapes while maintaining precise positioning.
: The AG3 integrates via TCP/IP, USB 2.0, CAN 2.0A, and optional EtherCAT, making it compatible with most industrial robot control systems. It operates on 24 V DC at 0.5 A rated current with a peak draw of 1.0 A.
: The AG3 is sealed with an IP40 protection rating and operates in controlled environments from 0 to 40°C, making it appropriate for food processing among other industries like automotive assembly and electronics manufacturing. Its quiet operation at under 60 dB also suits noise-sensitive production areas.
: The DH Robotics AG3 can handle a maximum workpiece weight of 1.8 kg with gripping forces between 10 and 65 N per jaw. The exact grip strength depends on the workpiece geometry and how the adaptive fingers conform to it.

Electric adaptive gripper vs pneumatic or magnetic alternatives:

The AG3 is a three-finger electric gripper designed for precise, quiet handling of lightweight parts up to 1.8 kg. It differs from pneumatic grippers in power source and from magnetic grippers in grip method. Choose it when precision, low noise, and adaptive finger conformance to irregular shapes matter more than raw force or speed.

For delicate electronics assembly or food handling, the sub-60 dB noise and ±0.03 mm repeatability avoid disruption and ensure positioning accuracy.
On shared collaborative cells with sensitive workpieces under 1.8 kg, adaptive three-finger linkage conforms to cylinders, sheets, and irregular geometries without hard jaw damage.
In controlled indoor environments (0–40°C), the IP40 seal and 24 V DC supply integrate into standard factory automation without special air lines or magnetic field constraints.
For pick-and-place or machine tending where force scaling matters, the 10–65 N range per jaw lets you dial grip strength down for fragile parts or up for secure transfer.
