The Mech-Eye NANO is a matrix-type 3D vision sensor built for close-range industrial imaging tasks.
Its compact form factor and low working distance make it well-suited for robot-mounted applications and assembly work where space is constrained.
The sensor is housed in an IP65-rated enclosure for protection against dust and water ingress in industrial environments.
The NANO captures accurate dimensional data from challenging surface types, including complex geometries and reflective materials.
This capability supports applications such as bin picking, part identification, and robotic guidance where varied surface characteristics would otherwise complicate vision-based detection.
The sensor delivers 3D point cloud data that can be processed for object recognition, grasp point calculation, and path planning in automated systems.
Fanless thermal management eliminates moving parts while maintaining operational stability.
The unit integrates illumination sources directly into its compact aluminum housing, simplifying installation and reducing the number of discrete components required in a vision system setup.
